E.4 APOGEE FLN Point List Summary

This database is for APOGEE FLN Application 2721 and features 97 logical points: 29 Logical Analog Inputs (LAI), 35

Logical Analog Outputs (LAO), 19 Logical Digital Inputs (LDI) and 14 Logical Digital Outputs (LDO). These points configure,

control or monitor the operation of the drive.

Information to consider when referencing this table:

• Points not listed are not used in this application.

• A single value in a column means that the value is the same in English units and in SI units.

• Point numbers that appear in curly brackets, e.g. {03}, can be unbundled at the field panel.

Table E.3 APOGEE FLN Application 2721 Point Number Summary

Point

No.

Point

Type

Point Name

Factory

Default

(SI Units)

Engr. Units

(SI Units)

Slope

(SI Units)

Intercept

(SI Units)

Text

Off

Text

Z1000

Parameter

1 LAO

CTLR

ADDRESS

31 – 1 0 – – Z3-02

2 LAO

APPLICATI

– – 1 0 – – –

{03} LAI

FREQ

OUTPUT

0 HZ 0.01 0 – – U1-02

{04} LAI

PCT

OUTPUT

0 PCT 0.01 0 – – –

{05} LAI SPEED 0 RPM 1 0 – – –

{06} LAI CURRENT 0 AMPS (A)

0.01/0.1

<1>

0 – – UB-01

{07} LAI TORQUE 0 PCT 0.1 0 – – –

{08} LAI POWER 0 KW

0.01/0.1

<1>

0 – – U1-08

{09} LAI

DRIVE

TEMP

0 DEG F / C 1 0 – – U4-08

{10} LAI

DRIVE

KWH

0 KWH 0.1 0 – – U4-10

{11} LAI MWH 0 MWH 1 0 – – U4-11

{12} LAI RUN TIME 0 HRS 1 0 – – U4-01

{13} LAI

DC BUS

VOLT

0 VOLTS (V) 1 0 – – U1-07

{14} LAI

AC OUT

VOLT

0 VOLTS (V) 0.1 0 – – U1-06

15 LAI PAR N9.01 0 AMPS (A)

0.01/0.1

<1>

0 – – n9-01

{16} LAI

RUN

TIMEX10K

0 10K HR 1 0 – – U4-01

{17} LAI

FAULT

CODE

0 – 1 0 – –

U2-01/

UB-09

{18}

<2>

LDI MINOR FLT NO FLT – 1 0 FAULT NO FLT U1-12 (Bit 6)

{19} LDI MAJOR FLT NO FLT – 1 0 FAULT NO FLT UB-06 (Bit 2)

20 LAO OVRD TIME 1 HRS 1 0 – – –

{21} LDI FWD.REV FWD – 1 0 REV FWD U1-12 (Bit 2)

{22} LDO

CMD

REV.STOP

STOP – 1 0 REV STOP –

{23} LDI RUN.STOP STOP – 1 0 RUN STOP UB-06 (Bit 1)

{24} LDO

CMD

RUN.STOP

STOP – 1 0 FWD STOP –

{25} LDI

ZERO

SPEED

OFF – 1 0 ON OFF U1-12 (Bit 1)

{26} LDI

SPEED

AGREE

NO AGR – 1 0 AGREE NO AGR U1-12 (Bit 4)

{27} LDI

DRIVE

READY

NOTRDY – 1 0 READY NOTRDY U1-12 (Bit 5)

E.4 APOGEE FLN Point List Summary

YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual

409
