B.2 A: Initialization Parameters
u
A1: Initialization
No.
(Addr.
Hex)
Name Description Values Page
A1-06
(127)
Application Preset
Application Sel
0: Standard
0: General
1: Fan
1: Fan General
2: Fan with PI Control
2: Fan PI
3: Return Fan with PI Control
3: Fan ReturnAir/PI
4: Cooling Tower Fan
4: Cooling Tower
5: Cooling Tower Fan with PI Control
5: CoolingTower/PI
6: Pump (Secondary)
6: Pump Secondary
7: Pump with PI Control
7: Pump PI
Default: 0
Range: 0 to 7
118
B.2 A: Initialization Parameters
YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual
309
B
Parameter List
